Di Blasi R7E Faltmokick
Di Blasi folding scooter R7E
The Di Blasi folding scooter R7E is powered by a 49.9 cc two-stroke engine and is equipped with an automatic speed variator. It can reach a speed of up to 45 km/h.
Open:
Dimensins: 128x92x58 cm
Step 92 cm
Folded
Size: 79 x 35 x 61 cm
Weight
Empty mass: 31.5 kg
Motor
brand & amp; type DI BLASI M1
Single cylinder, two-stroke
bore 39 mm
41.8 mm stroke
49.9 cc engine capacity
compression ratio 8.65: 1
max 0.86 kW power at 4000 r / min
2:56 mN max torque at 3000 r / min
Electrical system 12V-65W Candle:
NGK BR6HS
AC R42CF
BOSCH WR7A
CHAMPION QL7J5
DENSO W20FSR-U
MARELLI CW7NR
Carburetor:
Dell’Orto SHA 14-12
Getto: 53
Diffuser: 12 mm
Fuel: 2% mixture of oil
Primary drive V-belt drive
Report: min 1: 1,577 – 1 max: 3,736
Final drive: synchronous belt
Report: 22/102=1: 4.636
Lever start Tank 3 liters Consumption 35 km / l (about) Maximum speed: 45 km / h
Maximum gradient: about
Places: 1
Carrying capacity: 110 kg
Wheels
Need (front & amp; post) 5 “
Tyres (Front & amp; post) 4.00-5 “
Elastic suspensions on two wheels
Brakes
Brakes (front & amp; post) Ø 70 mm
Equipment:
